LW-550 synchronous laser welding machine

The principle of laser welding is that two types of plastics are clamped together under low pressure, and the laser beam is focused on two types of polymer products. One type of polymer plastic product is transparent to near-infrared laser, while the other type of plastic product absorbs the laser. The plastic that absorbs the laser energy converts the light energy into heat energy, which melts at the contact surface of the plastic. At the same time, the heat is also conducted to the surface of the plastic that transmits near-infrared light, forming a melting zone.Under the action of clamping force, molecular mixing occurs in the melting area, which forms a weld seam after cooling.

Equipment Functional Characteristics

High welding strength with water tightness and air tightness;
Welding does not produce smoke, pollution;
Fast welding speed and high efficiency;
Accurate control of melting and welding depth;
High quality, clean, and particle free welds.

Equipment parameters

Equipment parameters	Equipment parameters
Machine weight: 3000Kg	Electrical interface :3380V.50Hz.PE.N(5*16mm)
Machine Size:2250x1390x2145mm	Pneumatic interface :Ф12ncm
Driven type :Servo motor Precision gear drive	Tool interface:5 Port with HARTING Enthercat
PLC/OPC type(standard,choosable):CX5140/CP2615	Front door size(LxW)(mm):1200x748
Table position control: Displacement gauge(closed loop)	Back door size(HxW)(mm):1710x1128
Wwlding depth control: Displacement gauge(closed loop)	Lower mold size(LxW)(mm):990x550
Pneumatio Input air(bar):6-10 bar	Mold size on the mold{lxwimm):990x550
Pneumatic type :FESTO	Vacuum :Vacuum oump 2-way circuit
Humidity(without condensation):30-90%	Table stroke:500mm
Altitude:max,100@m	Welding property(maximum supported wire length): 1500mm
